| Engine Type | Longitudinal V 60° twin;, 4-stroke. Anti-vibration double countershaft (AVDC patent) |
| Fuel | 95 RON unleaded petrol |
| Cooling | Liquid cooled, with 3 way pressurised circuit; double radiator; circuit capacity 2.6 litres |
| Bore & Stroke | 97 x 67.5 mm |
| Displacement | 997.62cc |
| Compression Ratio | 11.4:1 |
| Distribution | 4 valves per cylinder, double overhead camshaft operated by a mixed gear/chain system |
| Feeding | Integrated system for electronic engine management. Indirect multi-point injection. 51 mm diameter throttle bodies. |
| Ignition | Electronic digital with TSI Twin Spark Ignition per cylinder integrated with injection |
| Start-up | Electric |
| Battery | 12V |
| Alternator | 400W |
| Lubrication | Dry sump with separate oil reservoir, double trochoidal pump with oil cooling radiator |
| Primary Transmission | Straight tooth gear, transmission ratio: 60/31 |
| Gearbox | 6 ratio transmission |
| End Transmission | Chain; transmission ratio: 42/17 |
| Clutch | Multiple disk in oil bath with power-assisted hydraulic control (PPC patent) |
| Frame | Aluminium alloy box-type sloping double beam, removable aluminium alloy saddle mount. Ohlins Racing double chamber steering damper & single block attachment. |
| Front Suspension | Showa 43mm upside-down fork with adjustment for preload, compression and rebound dampening. 120mm wheel travel. |
| Rear Suspension | Aluminium alloy swingarm with differential section members. APS (Aprilia Progressive System) linkage. Boge hydraulic monoshock with adjustment for preload, compression & rebound dampening. Wheel travel 135mm. |
| Front Brakes | Brembo double stainless steel floating disks, 320mm diameter; caliper with 4 pistons 34mm diameter; 4 pads in sintered material metal braid brake tubes. |
| Rear Brakes | Brembo stainless steel disc, 220mm diameter. Caliper with 2 pistons, 32mm diameter; metal braid brake tubes & pads in sintered material. |
| Wheels | Forged aluminium alloy; Front: 3.50 x 17"; Rear: 6.00 x 17" |
| Tyres | Tubeless radial; Front: 120/70 ZR17 Rear: 190/50 ZR17 (alternative: 180/55 ZR17) |
| Fuel Capacity | 18 litres (reserve 4 litres) |
| Dry Weight | 183kg (Front 50%, Rear 50%) |
| Dimensions | Length: 2070 mm Height: 1200 mm Width: 800 mm Wheelbase: 1415 mm. Seat Height: 820 mm |
Source: John Sample Group
