Configuration:
Single cylinder, four stroke, SOHC, 4 valves per cylinder
Cooling:
Liquid Cooled
Capacity:
198cc
Bore & Stroke:
62 x 58.4 mm
Compression Ratio:
11.2:1
Starter:
Electric
Ignition:
Electronic C.D.I
Fuel System:
Keihin CVK 26, 25mm dia. diffuser
Lubrication:
Forced wet crankcase lubrication with trochoidal pump
Gear Box:
Automatic converter
Primary Transmission:
V Belt
Final Drive Adapter with gears
Clutch:
Automatic centrifugal
Framed
Split single beam double cradle in high tensile tubular steel
Front Suspension:
Telescopic hydraulic fork, 35 mm dia. sleeves, travel 110 mm
Rear Suspension:
Engine functions as swinging fork swingarm, linked to the frame by dual connecting rods and two radial silent blocks. Single hydraulic double-action shock absorbers with preload adjustment, laterally mounted
Brakes Front:
stainless steel disk, 260 mm dia., two-pot floating caliper, 25 mm dia. Rear: stainless steel disk, 220 mm dia., caliper with two opposing pistons, 32 mm dia.
Wheels:
5-spoke light alloy. Front" 2.5" x 16" Rear: 3.00" x 16"
Tyres Front:
100/80/16 Rear: 130/80/16
Dimensions Length:
2080 mm
Height:
1330 mm
Width:
720 mm
Saddle Height:
800 mm
Wheelbase:
1415 mm
Dry Weight
151kg
Fuel Tank Capacity:
9.5 litres (including 2 litre reserve)
Source: John Sample Group
