| Engine | |||||||||||||
| Configuration | 4 stroke 90° V-Twin, DOHC, 4 valves per cylinder, Desmodromic, liquid cooled. | Lubrication | Forced feed gear pump w/oil cooler | ||||||||||
| Bore & Stroke | Ignition | Electronic I.A.W. type
Champion RA 59 GC |
|||||||||||
| Capacity | 916cc | Charging system | |||||||||||
| Compression Ratio | 11 : 1 | Starter | |||||||||||
| Maximum Power | 109 HP @ 9000 RPM (Crank) | Transmission | |||||||||||
| Maximum Torque | Gearbox | 6-speed with straight cut primary gears | |||||||||||
| Fuel | Weber electronic indirect injection | Clutch | Multiplate dry clutch | ||||||||||
| Chassis | |||||||||||||
| Frame | Trestle type constructed of "ALS 450" steel alloy
Rake: (2 position adjustable) 23°30' - 24°30' Trail: 91-97 mm / 3.6 - 3.8 in. |
Wheels | MT 3.50 x 17"
MT 5.50 x 17" |
||||||||||
| Dimensions |
|
Tyres | 120/70-ZR17
190/50-ZR17 |
||||||||||
| Front Suspension | 43 mm adjustable Showa inverted fork, 120 mm travel | Brakes | Dual 320 mm floating rotors with Brembo 4-piston calipers
Fixed 220 mm rotor with floating caliper |
||||||||||
| Rear suspension | Progressive linkage with adjustable monoshock | Fuel Capacity | 17 Litres (4.5 US gal) with 4 L reserve | ||||||||||
