Specifications
Bore & stroke: 59.8 x 62 mm
Compression ratio: 7.0:1
Engine Capacity: 175cc
Maximum power: 10 h.p. / 6,500 rpm
Valve: DOHC
Valves per cylinder: 2
Carburettor: Dell'Orto
Cooling system: Air cooled
Lubrication: Wet sump forced circulation with mechanical gear pump
Transmission: Gear primary, chain final
Clutch: Cable operated with multiple wet disc in oil bath
Gearbox: 4 Speed foot-change
Starter: Kick-starter
Throttle: Cable operated
Frame type: Open cradle tubular and pressed steel
Front Suspension: Telescopic fork and shock absorbers
Rear Suspension: Swingarm with hydraulic shock absorbers
Front Brake: Drum
Rear Brake: Drum
Seat: Ducktail solo seat
Fuel tank capacity: Approx. 14 litres
Weight: 100kg (220lb)
Top speed: 160 km/h (100 mph)
Source: Hessink's NL
